SimpleComTools, LLC
COM1000
 User Manual
SimpleComTools, LLC
TCP Destination IP
Destination IP Address of remote TCP Server.
Accepts numeric IP Address or fully qualified domain name (abc.123.com).
(Accepts up to 50 characters)
TCP Destination Port
Destination port of remote TCP Server.
nnnnn = (5 digit value with range between 1 and 65535)
TCP Connect Retries
TCP Connection Retries = number of times to retry making a connection to the
TTCPDESTIP remote IP address after a failed connection attempt.
Connection attempts will occur every 30 seconds.
Options:
0 = none (Do Not Retry)
255 = number of retries
TCP Inactivity Timer
TCP inactivity timer. Device will drop TCP connection if there is no data flow for the
stated period of time.  (n =0
255 Seconds)
TCP Session Timer
TCP Session connection timer. TCP Client will drop TCP connection after the stated
period of time. (n = 0
255 Seconds)
TCP Server Enabled
Local TCP/Device Server Application.
Options:
0 = Not Enabled (DEFAULT)
1 = Enabled
TCP Server Port
Local TCP/Device Server application port used to receive incoming
TCP connections.  nnnnn = (5 digit value with range between 1 and 65535)
TCP Server
Inactivity Timer
TCP/Device Server inactivity timer. Device Server will drop TCP connection if there is
no data flow for the stated period of time.  (n =0
255 Seconds)
Event Message
Customizable Terminal Port message text. This is a free
text field to be used when the
Terminal Port Applications (*TAPP) are set to #3 or #4 (SMTP or SMS). This text will be
seen as the message SUBJECT field.
(Accepts to 20 characters)
Recipients
Desired message recipient(s) as detailed in Message Config registers.
(Comma separation for multiple, ie 1,2,3,4,5,6,7,8)  Max number = 8.
Escape String
Sets terminal port escape string. Accepts alphanumeric value up to 20 characters.
Used for setting the value required by the COM1000 to escape from a session.
Example:  +++
Hangup String
Sets terminal port hangup string. Accepts alphanumeric value up to 20 characters.
Used for setting the value required by the COM1000 to hangup a session.
Example: ATH
