SimpleComTools, LLC
COM1000
 User Manual
SimpleComTools, LLC
Elapsed Timer 1
Terminal Port Application #1 Timer Trigger. Value 'n' is in minutes. This is the period of
time to wait before executing *TAPP1. This value requires that TERMINAL PORT APP
#1 TRIGGER be set to 1 (Timer).
Elapsed Timer 2
Terminal Port Application #2 Timer Trigger. Value 'n' is in minutes. This is the period of
time to wait before executing *TAPP1. This value requires that TERMINAL PORT APP
#2 TRIGGER be set to 1 (Timer).
Elapsed Timer 3
Terminal Port Application #3 Timer Trigger. Value 'n' is in minutes. This is the period of
time to wait before executing *TAPP1. This value requires that TERMINAL PORT APP
#3 TRIGGER be set to 1 (Timer).
Data Stream 1
Serial Data Stream used to trigger events (Up to 20 characters). This is the exact text
being filtered before executing any of the *TAPP selections. This value requires that
TERMINAL PORT APP #1 TRIGGER be set to 3 (Stream).
Data Stream 2
Serial Data Stream used to trigger events (Up to 20 characters). This is the exact text
being filtered before executing any of the *TAPP selections. This value requires that
TERMINAL PORT APP #2 TRIGGER be set to 3 (Stream).
Data Stream 3
Serial Data Stream used to trigger events (Up to 20 characters). This is the exact text
being filtered before executing any of the *TAPP selections. This value requires that
TERMINAL PORT APP #3 TRIGGER be set to 3 (Stream).
Inter Character Timer
Terminal Port Inter
Character Timer. (n = 1
5000 milliseconds). This is the length of the
pause between characters in the serial data stream before executing any of the *TAPP
selections. This value requires that TERMINAL PORT APP #1, 2 or 3 TRIGGER be set
to 2 (Inter
character Timer).
Buffer Size
Terminal Port Application Buffer. Value 'n' is in BYTES. This is the amount of data
being stored in the buffer before executing any of the *TAPP selections. This value
requires that TERMINAL PORT APP #1, 2 or 3 TRIGGER be set to 4 (Buffer).
UDP Destination IP
Destination IP Address of remote UDP Server.
Accepts numeric IP Address or fully qualified domain name (abc.123.com).
(Accepts up to 50 characters)
UDP Destination Port
Destination port of remote UDP Server.
nnnnn = (5 digit value with range between 1 and 65535)
UDP Server Enabled
Local UDP/Device Server Application.
Options:
0 = Not Enabled (DEFAULT)
1 = Enabled
UDP Server Port
Local UDP/Device Server application port used to receive incoming
UDP connections.  nnnnn = (5 digit value with range between 1 and 65535)
