SimpleComTools, LLC
COM1000
 User Manual
SimpleComTools, LLC
Active State Name
Customized Digital Input ACTIVE switch state name. A free
text field used when the
switch is in the ACTIVE state. Name will be used in all UDP, TCP, SMS, and SMTP
messages. For SMS and SMTP, this will be seen as the SUBJECT field.
(Accepts up to 20 characters). The message BODY is set by General- Status Message.
Inactive State Name
Customized Digital Input INACTIVE switch state name. A free
text field used when the
switch is in the INACTIVE state. Name will be used in all UDP, TCP, SMS, and SMTP
messages. For SMS and SMTP, this will be seen as the SUBJECT field.
(Accepts up to 20 characters). The message BODY is set by General- Status Message
Active State Message
Customized Digital Input #1 ACTIVE switch state message. A free
text field used when
the switch is in the ACTIVE state. Text is used in all UDP, TCP, SMS, and SMTP
messages. For SMS and SMTP, this will be seen as the SUBJECT field.
(Accepts up to 20 characters). The message BODY is set by General- Status Message
Inactive State Message
Customized Digital Input #1 INACTIVE switch state message. A free
text field used
when the switch is in the ACTIVE state. Text is used in all UDP, TCP, SMS, and SMTP
messages. For SMS and SMTP, this will be seen as the SUBJECT field.
(Accepts up to 20 characters). The message BODY is set by General- Status Message.
Event Recipients
Desired message recipient(s) as detailed in the MESSAGING configuration registers.
(Comma separation for multiple, ie 1,2,3,4,5,6,7,8)  Max number = 8.
UDP Destination IP
Destination IP Address of remote UDP Server that will receive Digital Input messages.
Accepts numeric IP Address or fully qualified domain name (abc.123.com).
(Accepts up to 50 characters)
UDP Destination Port
Destination port of remote UDP Server receiving Analog messages.
nnnnn = (5 digit value with range between 1 and 65535)
TCP Destination IP
Destination IP Address of remote TCP Server receiving Digital Input messages.
Accepts numeric IP Address or fully qualified domain name (abc.123.com).
(Accepts up to 50 characters)
TCP Destination Port
Destination port of remote TCP Server receiving Analog messages.
nnnnn = (5 digit value with range between 1 and 65535)
Reset Counters
Reset the Digital Input  value after reporting of the counters.
Options:
0 = Disabled (DEFAULT)
1 = Enabled
