SimpleComTools, LLC
COM1000
 User Manual
SimpleComTools, LLC
High Alarm Message
Customizable High Alarm Message text. This is a free
text field to be used when the
High Alarm Action (*AHIGHALARMACT) is set to #1, 2, or 3. This text will be seen as
the message SUBJECT field in SMS or SMTP messages. (Accepts to 20 characters).
The message BODY is set by General- Status Message. Example: site 1 high alarm.
arning Message
Customizable High Warn Message text. This is a free
text field to be used when the
High Warn Action (*AHIGHWARNACT) is set to #1, 2, or 3. This text will be seen as the
message SUBJECT field in SMS or SMTP messages. (Accepts to 20 characters
The message BODY is set by General- Status Message. Example: site 1 high warn.
Low Warning Message
Customizable Low Warn Message text. This is a free
text field to be used when the Low
Warn Action (*ALOWWARNACT) is set to #1, 2, or 3. This text will be seen as the
message SUBJECT field in SMS or SMTP messages. (Accepts to 20 characters).
The message BODY is set by General- Status Message. Example: site 1 low warn.
Low Alarm Message
Customizable Low Alarm Message text. This is a free
text field to be used when the
Low Alarm Action (*ALOWALARMACT) is set to #1, 2, or 3. This text will be seen as
the message SUBJECT field in SMS or SMTP messages. (Accepts to 20 characters).
The message BODY is set by General- Status Message. Example: site 1 low alarm.
Event Recipients
Desired message recipient(s) as detailed in the MESSAGING configuration registers.
(Comma separation for multiple, ie 1,2,3,4,5,6,7,8)  Max number = 8.
UDP Destination IP
Destination IP Address of remote UDP Server that will receive Analog messages.
Accepts numeric IP Address or fully qualified domain name (abc.123.com).
(Accepts up to 50 characters)
UDP Destination Port
Destination port of remote UDP Server receiving Analog messages.
nnnnn = (5 digit value with range between 1 and 65535)
TCP Destination IP
Destination IP Address of remote TCP Server receiving Analog messages.
Accepts numeric IP Address or fully qualified domain name (abc.123.com
(Accepts up to 50 characters)
TCP Destination Port
Destination port of remote TCP Server receiving Analog messages.
nnnnn = (5 digit value with range between 1 and 65535)
Reset Counters
Reset the ANALOG COUNTER value after reporting of the counters.
ptions:   0 = Disabled (DEFAULT)
1 = Enabled
Minimum Analog Voltage
Minimum voltage output of the chosen sensor. Typically ‘0’, but this may be 1 or 5.
Check the sensor specifications for details..
Maximum Analog Voltage
Maximum voltage output of the chosen sensor. May not be greater than 30 VDC.
Check the sensor specifications for details.
