SimpleComTools, LLC
COM1000
 User Manual
SimpleComTools, LLC
ANALOG INPUT
The Analog Input tab configures the desired Warning and Alarm values (Set Points) for the Analog Input.
Options include High Alarm Set Point, High Warning Set Point, Low Warning Set Point and Low Alarm Set Point:.
Actions include sending data out of the serial port, to sending IP packets, SMS or SMTP or IM messages.
The tab makes it simple to configure the analog set points, the warning and alarm messages, as well as the intended
message recipients.
Parameter Name
Description
Name
Customized ANALOG Interface Name. A free
text field for the NAME of the interface
which will be used in all UDP, TCP, and SMTP alerts. For SMTP and SMS alerts, this
will be seen as the FROM field. Accepts up to 20 characters.
Example: analoginterface
Current Value
Displays the current Analog value.
High Alarm Count
Displays the current High Alarm Count.
This is the number of times that this particular Set Point has been reached.
High Warning Count
Displays the current High Warning Count.
This is the number of times that this particular Set Point has been reached.
Low Warning Count
Displays the current Low Warning Count.
This is the number of times that this particular Set Point has been reached.
Low Alarm Count
Displays the current Low Alarm Count.
This is the number of times that this particular Set Point has been reached.
High Alarm Set Point
High Alarm Set Point is the highest analog value you wish to allow.
Reaching this value will trigger the selected HIGH ALARM ACTION(S).
Acceptable values range from 0.0
30.0, with .1 increments.
(Example:  26.5).
High Warning Set Point
High Warning Set Point is a higher analog value you wish to be warned about.
Reaching this value will trigger the selected HIGH ALARM ACTION(S).
Acceptable values range from 0.0
30.0, with .1 increments.
(Example:  20.2).
Low Warning Set Point
Low Warning Set Point is a lower analog value you wish to be warned about.
Reaching this value will trigger the selected LOW WARNING ACTION(S).
Acceptable values range from 0.0
30.0, with .1 increments.
ple:  5.2).
Low Alarm Set Point
Low Alarm Set Point is the lowest analog value you wish to allow.
Reaching this value will trigger the selected LOW ALARM ACTION(S).
Acceptable values range from 0.0
30.0, with .1 increments.
(Example:  1.5).
