SimpleComTools, LLC
COM1000
 User Manual
SimpleComTools, LLC
FTP / SYSLOG
The FTP and SYSLOG clients embedded in the COM1000
used for transporting files and messages created
during event captures.
Parameters for FTP and SYSLOG client connections and file naming conventions are
configured on this tab.
Parameter Name
Description
FTP Server IP
IP or Domain Name of destination FTP Server.
Accepts n.n.n.n or abc.123.com (Up to 50 characters)
FTP Server Port
FTP Server Port. (DEFAULT = 21)
nnnnn = (5 digit value with range between 1 and 65535).
Username
FTP Account Username. (Accepts up to 20 characters).
Example:  johndoe
Password
FTP Account Password. (Accepts up to 20 characters).
Example:  password123
Passive Mode
By default, FTP data connections are initiated by an FTP client but actually established
by the FTP server. Passive Mode forces the data connections to be established by the
client. Passive mode may be required for users who are behind some types of router
based firewalls or behind a gateway requiring passive transfers.
Options:
0 = Passive Mode Disabled (Default)
1 = Passive Mode Enabled
Directory/Path
Sets the Initial Remote Host Directory on the FTP server.
Syntax dictates that you must start the directory path with a slash '/'.
Example: /com1000  (DEFAULT = No path <root>)
File Name
FTP Remote File Name Syntax.
Options:
0 = HOSTNAME.txt    (Name of device)   (DEFAULT)
1 = HOSTNAME_n.txt    (Name of device + incrementing number)
2 = HOSTNAME_DATE.txt    (Name of device + date)
3 = HOSTNAME_DATE_n.txt    (Name of device + date + number)
4 = HOSTNAME_DATE_TIME.txt    (Name of device + date + time)
Scheduled FTP Type
Scheduled FTP Event data type
Options:
0 = None   (DEFAULT)
1 = Status (The STATUS events specified in the General Tab)
2 = Log  (Individual event LOG)
Scheduled FTP Timer
Scheduled FTP Event time (in minutes)
Options: 0 = not active (DEFAULT)
65535 = # of minutes between updates (44640 min = 1 month)
SYSLOG Server IP
IP or Domain Name of destination SYSLOG Server.
Accepts n.n.n.n or abc.123.com (Up to 50 characters)
SYSLOG Server Port
SYSLOG Server Port. (DEFAULT = 514)
nnnnn = (5 digit value with range between 1 and 65535).
Scheduled
SYSLOG Type
Scheduled SYSLOG Event data type
Options:
0 = None   (DEFAULT)
1 = Status (The STATUS events specified in the General Tab)
Scheduled
SYSLOG Timer
Scheduled SYSLOG Event time (in minutes)
Options: 0 = not active (DEFAULT)
65535 = # of minutes between updates (44640 min = 1 month)
