SimpleComTools, LLC
COM1000
 User Manual
SimpleComTools, LLC
MESSAGING
The Messaging tab is for configuring COM1000 message methods, timing parameters, and message recipients.
COM1000 “messages’ are either SMS/text messages or SMTP/email messages, so you will need to select a method
SMS or Email) and then complete the other parameters necessary to make sure messages are sent correctly.
Parameter Name
Description
Message Method
Outbound Message Notification Method.
Options:
0 = None (Default)
1 = SMS
2 = SMTP
Active Message
quency
Frequency of Repeat ACTIVE Event Messages. This value controls the behavior when
a Digital Input state or Analog Input value has not changed, and a repeat message is
about to be sent. Default is once every 30 MINUTES.
Options:
0 = Unlimited (Repeat messages will occur indefinitely; [5 seconds])
1 = Once
(Repeat messages suppressed, no repeats)
2 =  1 MIN
(Repeat messages sent once every  1 MIN)
3 = 30 MIN
(Repeat messages sent once every 30 MIN)
4 = 60 MIN
(Repeat messages sent once every 60 MIN)
5 =  4 HRS
(Repeat messages sent once every  4 HRS)
6 =  8 HRS
(Repeat messages sent once every  8 HRS)
7 = 24 HRS
(Repeat messages sent once every 24 HRS)
8 = WEEKLY
(Repeat messages sent once every 7 DAYS)
9 = MONTHLY
(Repeat messages sent once on
DAY or Month)
Inactive Message
Frequency
Frequency of Repeat ACTIVE Event Messages. This value controls the behavior when
a Digital Input state or Analog Input value has not changed, and a repeat message is
about to be sent. Default is once every 30 MINUTES.
Options:
0 = Unlimited (Repeat messages will occur indefinitely; [5 seconds])
1 = Once
(Repeat messages suppressed, no repeats)
2 =  1 MIN
(Repeat messages sent once every  1 MIN)
3 = 30 MIN
(Repeat messages sent once every 30 MIN)
4 = 60 MIN
Repeat messages sent once every 60 MIN)
5 =  4 HRS
(Repeat messages sent once every  4 HRS)
6 =  8 HRS
(Repeat messages sent once every  8 HRS)
7 = 24 HRS
(Repeat messages sent once every 24 HRS)
8 = WEEKLY
(Repeat messages sent once every 7 DAYS)
MONTHLY
(Repeat messages sent once on 1
DAY or Month)
SMTP Server IP
IP or Domain Name of SMTP Server.
Accepts n.n.n.n or abc.123.com (Up to 50 characters)
SMTP Server Port
SMTP Server Port.
nnnnn = (5 digit value with range between 1 and 65535). (Default value = 25)
Use Authentication
SMTP Server  Uses Authentication
Options:
0 = Authentication Disabled (Default)
1 = Authentication Enabled
Email for Authentication
EMAIL to be used for SMTP Authentication. Format is user@domain.com.
Accepts up to 20 characters.
User Name
SMTP Account Username. Accepts up to 20 characters.
Example:  johndoe
Password
SMTP Account Password. Accepts up to 20 characters.
Example:  password123
