SimpleComTools, LLC
COM1000
 User Manual
SimpleComTools, LLC
Buffer Size
485 Port Application Buffer. Value 'n' is in BYTES. This is the amount of data being
stored in the buffer before executing any of the *TAPP selections. This value requires
that RS
485 PORT APP #1, 2 or 3 TRIGGER be set to 4 (Buffer).
UDP Destination IP
Destination IP Address of remote UDP Server.
Accepts numeric IP Address or fully qualified domain name (abc.123.com).
(Accepts up to 50 characters)
UDP Destination Port
Destination port of remote UDP Server.
nnnnn = (5 digit value with range between 1 and 65535)
UDP Server Ena
Local UDP/Device Server Application.
Options:
0 = Not Enabled (DEFAULT)
1 = Enabled
UDP Server Port
Local UDP/Device Server application port used to receive incoming
UDP connections.  nnnnn = (5 digit value with range between 1 and 65535)
TCP Destination IP
Destination IP Address of remote TCP Server.
Accepts numeric IP Address or fully qualified domain name (abc.123.com).
(Accepts up to 50 characters)
TCP Destination Port
Destination port of remote TCP Server.
nnnnn = (5 digit value with range between 1 and 65535)
TCP Connect Retries
TCP Connection Retries = number of times to retry making a connection to the
TTCPDESTIP remote IP address after a failed connection attempt.
Connection attempts will occur every 30 seconds.
Options:
0 = none (Do Not Retry)
255 = number of retries
TCP Inactivity Timer
TCP inactivity timer. Device will drop TCP connection if there is no data flow for the
stated period of time.  (n =0
255 Seconds)
TCP Session Timer
TCP Session connection timer. TCP Client will drop TCP connection after the stated
period of time. (n = 0
255 Seconds)
TCP Server Enabled
Local TCP/Device Server Application.
Options:
0 = Not Enabled (DEFAULT)
1 = Enabled
TCP Server Port
Local TCP/Device Server application port used to receive incoming
TCP connections.  nnnnn = (5 digit value with range between 1 and 65535)
TCP Server
Inactivity Timer
TCP/Device Server inactivity timer. Device Server will drop TCP connection if there is
no data flow for the stated period of time.  (n =0
255 Seconds)
