SimpleComTools, LLC
COM1000
 User Manual
SimpleComTools, LLC
DIGITAL INPUT (1-4)
The (4) Digital Inputs provide the ability to capture contact closures, log those events and/or send message
notifications that an event has occurred. The (4) Digital Input  tabs are used to configure these inputs with unique
Active and Inactive state names and actions. Options include naming the interfaces, selecting contact closure/switch
types, as well as selecting Actions such as sending data out of the serial port, to sending IP packets, SMS or SMTP
or IM messages.
Parameter Name
Description
Name
Customized Digital Input Name. A free
text field for the NAME of the interface which will
be used in all UDP, TCP, and SMTP alerts. For SMTP and SMS alerts, this will be seen
as the FROM field. Accepts up to 20 characters.
Example: west_door
Current Value
Displays the current Digital Input value.
rrent Count
Displays the current Digital Input count.
Switch Type
Digital Input Switch Type. The chosen selection will be considered the INACTIVE
STATE for all of the events and messages. For example, if the switch is Normally
Open, then an open switch is INACTIVE. When the switch is closed, it becomes
ACTIVE. The same is true for the reverse. If the switch is Normally Closed, then a
closed switch is INACTIVE and open is considered ACTIVE.
Options:   0 = Normally Closed
1 = Normally Open
Active State Action
Digital Input ACTIVE switch state action. Event that will be triggered when the switch
connected to the digital input changes to the ACTIVE state.
Options:   0 = No Action
1 = Terminal Port (ASCII Data Stream)
2 = RS485 Port (ASCII Data Stream)
3 = UDP Alert
4 = TCP Alert
5 = Send Message
6 = FTP
7 = Relay OPEN
8 = Relay CLOSE
9 = COUNT events
10 = LOG events
(Use comma separation for multiple selections; ie 1,3,7)
Inactive State Action
Digital Input  INACTIVE switch state action. Event that will be triggered when the switch
connected to the digital input changes to the INACTIVE state.
Options:   0 = No Action
1 = Terminal Port (ASCII Data Stream)
2 = RS485 Port (ASCII Data Stream)
3 = UDP Alert
4 = TCP Alert
5 = Send Mess
6 = FTP
7 = Relay OPEN
8 = Relay CLOSE
9 = COUNT events
10 = LOG events
(Use comma separation for multiple selections; ie 1,3,7).
